S695FCG3 Fanless Control MiniPC
Tuotenro
S695FCG3
Varastossa
0,00 EUR
- Intel Q370 core logic
- Support 8th & 9th generation Intel FCLGA1151 low power CPU
- Support SODIMM DDR4 2666/2400Mhz max 32GB
- On-board 4x gigabit LAN and six USB 3.1 ports
- On-board DVI-I and Display Port
- Dual mini-PCIe slots support one full size and one half size mini card
- Support 6Gb/s SATA 2.5" hard disk
- Power-on delay and remote power on/off
- Dimension W160mm x L250mm x H58mm
| System | |
| Processor |
Intel the 8thand 9thgeneration low power(35W) Core i7, i5, i3, Pentium and Celeron processors |
| CPU Performance | |
| Security Hardware | |
| Chipset | Intel Q370 |
| Storage | 2.5” SSD drive bay |
| Storage Support | |
| Memory | DDR4 2400/2666MHz non-ECC SODIMM, max 32GB |
| Graphics | Integrated Intel UHD graphics630 |
| I/O Ports | |
| USB 2.0 | - |
| USB 3.0 | 6x USB 3.1 Gen2 |
| Serial | 1x RS-232 |
| Video | 1 x DVI-I 1 x DP |
| Ethernet | 4x GbE LAN , RJ-45 (1x Intel219LM, 3x Intel211AT) |
| Other Ports | Mic-in/Line-out PS/2 Keyboard/Mice 1x Remote Power On/Off Connector |
| Expansion | |
| Expansion Interface | MiniPCIe |
| Operating System | |
| Operating System | Windows® 10 / LINUX |
| Power | |
| DC Input / Source Voltage | Power Input Voltage 12~48VDC |
| Operating Temperature | |
| Operating Temperature | -20°C ~ +55°C with W.T. SSD |
| Humidity Range | 10% ~ 95%, non-condensing |
| Cooling System / Thermal Solution | |
| Thermal Solution | Fanless |
| Dimensions / Weight | |
| Weight (kg) | 2.5 kg |
| Dimensions | 250 x 160 x 58 mm |
| Enclosure | |
| Bezel | |
| Material | Aluminum |
| Mounting | Desk / Wall mounting |
| Peripherals & Devices | |
| Accessories | Power Cable & Wall-mount accessories included |
| Extra Features | |
| Certification | |
| Certification | CE, FCC |
| Jäähdytys | Fanless |
|---|---|
| CPU Family | Coffee Lake Refresh (9th Gen Core i3/i5/i7) |
| Operating Temp | Wide Temp -10..50C |
