ARK-1250L
Tuotenro
ARK-1250L-x
Toimitusaika 21-30pv
1662,88 EUR 1325,00 EUR
Intel® 11th gen Core™ i processor with Triple LAN/ Quadruple COM Din-Rail Fanless Box PC
- i3-1115G4E CPU /Core i5-1145G7E
- DIN-Rail system with essential I/O ports on front-side bezel
- 3 x Intel GbE, 4x RS-232/422/485
- 3 x USB 3.2 and 3 x USB 2.0, dual independent displays with one 4K HDMI and one VGA
- 3 Expansion: M.2 E-Key 2230, M.2 B-Key 2280, 1 x Full-size mSATA share with mPCIe slot
- mSATA and 1 x 2.5" SATA storage device
- 12V ~ 24V wide range power input
- -40 ~ 60 °C extended operating temperature
- WISE-DeviceOn supported for quick AI deployment at scale
| System | |
| Processor | Intel Core i3-1115G4E / i5-1145G7E |
| Security Hardware | TPM2.0 (by optional module) |
| Chipset | SoC |
| Storage | 1 x 2.5” SATA HDD/SSD |
| Storage Support | |
| Memory | 2 x 260 pin DDR4-3200 non-ECC SO-DIMM, up to 64GB |
| Audio | |
| Graphics | Intel® Iris® Xe graphics |
| I/O Ports | |
| USB 2.0 | 3x USB2.0 |
| USB 3.0 | 3x USB 3.2 |
| Serial | 4x RS-232/422/485 |
| Video | 1 x HDMI 1.4 1 x VGA |
| Ethernet | 1 x 10/100/1000 Mbps Ethernet 3 x 10/100/1000/2500 Mbps Ethernet |
| Other Ports | 8bit GPIO Audio CAN-port (optional ) |
| Expansion | |
| Expansion Interface | 1 x mPCIe 1x M2. 2230 E key 1 x M.2 2280 B key with SIM holder |
| Operating System | |
| Operating System | Windows® 10, LINUX |
| Power | |
| DC Input / Source Voltage | 12-24VDC |
| Operating Temperature | |
| Operating Temperature | -40°C ~ +60°C (with Wide-Temp SSD, Memory) |
| Humidity Range | 10% ~ 90%, non-condensing |
| Vibration | 3 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis |
| Shock | 30 G, IEC 60068-2-27, half sine, 11 ms duration |
| Cooling System / Thermal Solution | |
| Thermal Solution | |
| Dimensions / Weight | |
| Weight (kg) | 1.5 kg |
| Dimensions | 60 x 173 x 141 mm |
| Enclosure | |
| Bezel | |
| Material | Aluminum / Steel |
| Mounting | Desk |
| Certification | |
| Certification | CE |
| Jäähdytys | Fanless |
|---|---|
| CPU Family | Tiger Lake (11th Gen Core i3/i5/7) Mobile |
| Operating Temp | Wide Temp -40..70C |
