AIE900-902-FL
Tuotenro
AIE900-902-FL
Toimitusaika 21-30pv
0,00 EUR
- NVIDIA® Jetson AGX Xavier™ with 512-core Volta GPU with 64 Tensor cores GPU
- High AI computing performance for GPU-accelerated processing
- Ideal for intelligent edge applications, AGV, AMR and computer vision
- Supports M.2 NVMe PCIe x4 SSD slot
- Wide operating temperature from -30°C to +50°C
- JetPack supported
| System | |
| Processor | NVIDIA® Jetson AGX Xavier™ |
| CPU Performance | 8-core Carmel ARM® v8.2 64-bit CPU, 8MB L2 + 4MB L3 |
| Security Hardware | |
| Chipset | SoC |
| Storage | Onboard 32GB eMMC (via Jetson AGX Xavier™) 1 x M.2 Key M 2280 with PCIe x4 NVMe SSD slot 1 x Micro SD slot 1 x 2.5" SSD/HDD drive bay |
| Memory | 1 x 32GB 256-Bit LPDDR4x onboard |
| GPU / Graphics | 512-Core NVIDIA Volta™ GPU with 64 Tensor Cores |
| I/O Ports | |
| USB 2.0 | 2x USB 2.0 |
| USB 3.0 | 2x USB 3.1 Gen1 2x USB 3.1 Gen2 |
| Serial | 2 x RS-232 default (or 2 x CAN by jumper settings) |
| Video | 2 x Lockable HDMI 2.0 with 4K2K supported |
| Ethernet | 2 x 10/100/1000 Mbps Ethernet (Intel® i210-IT) 4 x 10/100/1000 Mbps PoE (Intel® i210-IT) |
| Other Ports | 1 x 8-CH DI/DO |
| Expansion | |
| Expansion Interface | 1 x Full-size PCI Express Mini Card slot (USB + PCI
Express signal) 1 x M.2 Key E 2230 slot 1 x SIM slot |
| Operating System | |
| Operating System | Linux Ubuntu 18.04 support |
| Power | |
| DC Input / Source Voltage | 24 VDC |
| Operating Temperature | |
| Operating Temperature | -30°C ~ +50°C |
| Humidity Range | 10% ~ 95%, non-condensing |
| Cooling System / Thermal Solution | |
| Thermal Solution | Passive - Fanless |
| Dimensions / Weight | |
| Weight (kg) | 2.8 kg |
| Dimensions | 239 x 185.3 x 79.4 mm |
| Enclosure | |
| Bezel | |
| Material | Aluminum , IP40 |
| Mounting | Desk / Wall mounting DIN-Rail /VESA |
| Certification | |
| Certification | CE, FCC certified |
| Jäähdytys | Fanless |
|---|
