ABS-like 3D resin, White, 1L
Tuotenro
ABS-like_3D_resin_White_1L
Varastossa
43,93 EUR 35,00 EUR
3D printing resin, white, 1L, 405nm UV Cure
90% ABS 3D resin
Anti-scratch
Super strong and tenacity
Great weathering
Suitable for different post processing like drilling, screwing etc.
Non VOC, RoHS certificated
Technical specification | |
Flexural modulus | 1.192-2.525Mpa |
Flexural strenght | 68-80MPa |
Hot deformation temp | 65C |
Linear shrinkage | 1.05-1.35% |
Tensile strenght | 42-62MPa |
Tensile modulus | 1.86-2.645MPa |
Elongation at break | 4-10% |
Hardness (Shore D) | 82-85D |
Viscosity | 150-350MPa-s |
Printing parameter | |
ABS-like resins are perfectly on most brand LCD printer, and fast printing on DLPs. | |
Printing time | For LCD printer, bottom layer
30-70s and each layer exposure time 4-12s, for
example, layer thickness 50 micron on Anycubic printer, base 50s
while each layer 8s. For DLP printer, bottom 5-15s and each layer 1-5s. |
Cleaning and post-curing | 1), Spray with Isopropanol, then
blow resin away with cool wind. 2) Prepare two containers with Isopropanol (alcohol> 95%), and place the jobs into the first container and slightly shake it, then soak in the second container for about 1 minute 3)Flush with water before dry it, do make it sure it ‘s 100% dried as residuary alcohol may cause white spot or crack on jobs. |
Post-curing | 1) The curing time is
proportional to the volume of the work piece and inversely
proportional to the optical power of the curing chamber. Example:
100 watt LED curing box, jewelry jobs is recommended to be cured
with soaking in water for 20-30 minutes. 2) The post-cure time of dental casting resin, dental non-casting resin and jewelry mold resin shall not more than 5 minutes. 3) Work-pieces should be in the water during post-curing to prevent deformation especially for dental and jewelry. 4) Don’t forget to use cool air to dry it after post-curing. |
