SDC0880I

SKU

SDC0880I

Lead time 21-30 days

Industrial I/O Control PCIe Card 8+8-ch Isolated Digital I/O

Expands isolated eight (8) digital input channels with features for all channels.
- Support both NPN & PNP devices
- Support both dry and wet contact connections
- With digital filter for noise reduction
- Built-in 32-bit counter for all digital in channels
Expands isolated eight (8) NPN type digital output channels with initial value (Booting & Restart) protection.
Each channel built-in 2.5KV isolation protection for signal and power, allowing the input signals to be completely floated so as to prevent ground loops
Designed to meet PCI Express Base Specification Revision 2.1.
With high reliable SUNIX QiuNiu UART Digital-I/O controller.
Plug-n-Play, I/O address and IRQ assigned by system.

Board
Interface	PCI Express
Controller	SUNIX QiuNiu UART Digital-I/O Controller
BUS	PCI Express 1.0 x1
IRQ & IO	Assigned by System
ESD Protection	±15KV IEC61000-4-2 Air Gap Discharge ±8KV IEC61000-4-2 Contact Discharge

Digital Input Communication
Type	NPN & PNP
Channel	8-Channel
Dry Contact	Logic Level 0: Open; Logic Level 1: Close to GND
Wet Contact	Logic Level 0: 0 to 3VDC; Logic Level 1: 10 to 50VDC
Pin Define	DI1~DI8, COM, GND
Counter	32-bit counter for all channel
Interrupt Mode	Event trigger (Rising Edge, Falling Edge, Both modes) & polling for all channels
Noise Reduction	Digital Filter

Digital Output Communication
Type	NPN
Channel	8-Channel
Voltage Range	3.5 to 40VDC
Current	500mA per Channel
Pin Define	DO1~DO8, PWR, GND
Initial Protection	Initial Value Setup (Booting & Restart protection)
