    • Cost-effective with fanless and cableless design
    • Intel® Atom® Processor E3930
    • 6 isolated COM, isolated DIO (8-in/8-out), 3 GbE LAN
    • Wide operating temperature range from -40°C to +85°C
    • 9 to 36 VDC power input with OVP, UVP, OCP, RPP
    • Supports 5G connectivity
    • Supports TPM 2.0
    System
    Processor Intel® Atom® x5-E3930 1.3GHz/2C/6.5W
    Security Hardware TPM 2.0
    Chipset SoC
    Storage 1 x mSATA (occupied 1 x PCI Express Mini Card slot)
    1 x Internal 2.5" SATA drive (9.5 mm height)
    Memory 1 x DDR3L-1866 SO-DIMM, up to 8GB
    Audio
    Graphics 1 x HDMI (up to 1920 x 1200 @60Hz)
    I/O Ports
    USB 2.0 -
    USB 3.0 2 x USB 3.0
    Serial 2 x Isolated RS-232/422/485 (Phoenix Type)
    4 x Isolated RS-232/422/485 (4-wire, Phoenix Type)
    Video 1 x HDMI
    Ethernet 3 x RJ-45 isolated 10/100/1000 Mbps Ethernet (Intel® i211-AT) Isolation voltage: 1.5 kV
    Other Ports 1 x Isolated 8-in/8-out DIO
    Expansion
    Expansion Interface 1 x M.2 Key B 3052: USB 3.0 /PCIe (for 5G module)
    1 x Full-size Rev.1.2 PCI Express Mini Card slot: USB (for LTE/Wi-Fi module)
    1 x Half-size Rev.1.2 PCI Express Mini Card slot: USB/mSATA (for mSATA)
    2 x SIM Slot
    Operating System
    Operating System Windows® 10, LINUX
    Power
    DC Input / Source Voltage 24VDC
    Operating Temperature
    Operating Temperature -40°C ~ +70°C (with Wide-Temp SSD, Memory)
    Humidity Range 10% ~ 90%, non-condensing
    Vibration 3 Gms with storage (5 to 500Hz, X/Y/Z direction; random, operating)
    Shock
    Cooling System / Thermal Solution
    Thermal Solution Fanless
    Dimensions / Weight
    Weight (kg) 1.0 kg
    Dimensions 66 x 110 x 155 mm
    Enclosure
    Bezel
    Material Aluminum / Steel
    Mounting Desk / Wall mounting /DIN-rail
    Certification
    Certification

    CE/FCC
    UL
    ATEX/Class I Division 2

    More Information
    CoolingFanless
